Reyee Wireless Bridge Kit - Pre-Paired - 2.4GHz 500m Range
Reyee Wireless Bridge Kit - Pre-Paired - 2.4GHz 500m Range
Features:
- RG-EST100-E can easily transmit data from 500m away in real time
- Factory-free configuration, without complex alignment
- IP55 Weatherproof, -30℃~60℃ guarantee stable operating at outdoor or elevator environment
- Supports a maximum of 10 * 3MP cameras loading at 100m, 5 * 3MP cameras loading at 500m
- Visually Intuitive statistics monitoring on Ruijie cloud, easy remote maintenance
- Perfect for CCTV in elevators
Key Specification
Radio Design: 2.4 GHz Single-Band Dual-Stream
Operating Band: 802.11b/g/n: 2.400～2.483GHz
Polarization: Horizontal: 70°, Vertical: 70°
Spatial Streams: 2x2, MU-MIMO
Maximum Throughput: Up to 300 Mbps at 2.4 GHz
IP Rating: IP55
Installation: Wall-mounted/ Pole-mounted
Weight: 0.3 kg
Transmission Protocol: IEEE 802.11b/g/n
Antenna: Directional antennas, 8 dBi
Bridging Distance: 500m (recommended)
Memory/Flash: 64 MB/8 MB
Max. Transmit Power: ≤100 mW(20 dBm) (adjustable)
Lightning Protection: ±6 KV(Common Mode)
Dimensions （D x W x H）: 165.5mm×68.7mm×42mm
